HBC-BE160 ES
Busbar Bending Machine 160 x 15 mm
Stand-alone bender for busbars up to 160 x 15 mm.
- Function
- Bending Busbars
- Bender Capacity
- Up to 160 x 15 mm
- Operating Pressure
- 200 Bar
- Power Rating
- 1 x 2.2 Kw
Overview
The HBC-BE160 ES bends busbars up to 160 x 15 mm, with optional step, edge, twist and end-bending molds.
Key features
- Electronic bender controller with spring-back compensation
- Digital angle indicator for accurate bending
- Rotatable plates prevent damage to the busbar surface
- Optional step, edge-bending, twist and end-bending molds
- Programmable length stopper
- Processes copper and aluminium busbars
- Industry 4.0 ready
Advantages
- Bends heavier 160 x 15 mm busbars
- Repeatable bends with the programmable stopper
Technical Specifications
| Function | Bending Busbars |
|---|---|
| Bender Capacity | Up to 160 x 15 mm |
| Bender Controller | Electronic Controller, High Accuracy Encoder |
| Bender Molds | Step Mold (Optional), Edge Bending Mold (Optional), Twist Mold (Optional), End-Bending Mold (Optional) |
| Length Measuring in Bender | Programmable Length Stopper |
| Hydraulic System | One Power Pack, Double Acting System |
| Operating Pressure | 200 Bar |
| Power Rating | 1 x 2.2 Kw |
| Voltage | 380 Volt - 3/50 Hz |
| Oil | Hydraulic Oil H68 - 30 Liters |
| Main Desk Dimension | 246 x 110 x 95 (H) cm |
Applications
- Electrical panel and switchboard manufacturing
- Switchgear and MCC panels
- Busduct and busway fabrication
- Power distribution and transformer connections
